Version of the ballast.
The way the power can be connected.
The IP (Ingress Protection) code indicates the degree of protection against ingress of moisture and solid objects. The code consists of two firures. The first figure indicates the protection against objects and dust: IP 0x - not protected IP 1x - protected against objects with a diameter above 50 mm IP 2x - protected from objects with a diameter greater than 12 mm (touch safe) IP 3x - protected from objects with a diameter greater than 2.5 mm IP 4x - protected against objects with a diameter greater than 1 mm IP 5x - protected against dust ( dust ) IP 6x - dustproof
The second figure indicats the protection against water: IP x0 - unprotected (plain) IP x1 - Protected against dripping water (drip) IP x2 - Protected against dripping water when tilted to 15 degrees IP x3 - protected against spraying water (rain tight) IP x4 - protected against splashing water (splash proof) IP x5 - protected against water jets (splashproof) IP x6 - protected from rainstorms IP x7 - protected against accidental immersion (30 minutes to 1 meter deep) (waterproof) IP x8 - protected from stay under water (pressure proof)
Suitable for PL-C 2 Pin, Dulux D, Biax D Lynx CF-D lamps. You can only use lamps with the specified wattage and number. Other combinations will not work.
Suitable for PL-L 4, L Dulux, Biax L, Lynx CF-L lamps. You can only use lamps with the specified wattage and number. Other combinations will not work.
Suitable for PL-R 4-pin Dulux T / E HE High Efficiency GR14q-1 lamps. You can only use lamps with the specified wattage and number. Other combinations will not work.
Suitable for old "thick" T12 TL fluorescent tubes of 38mm. You can only use lamps with the specified wattage and number. Other combinations will not work.
Suitable for TL5 and TL5 HE HO, T5 FH and FQ T5, T5 and T5 FHE FHO, High Efficency T5 and T5 High Output lamps. You can only use lamps with the specified wattage and number. Other combinations will not work.
At the specified output has gone out of the standard length of the lamps. 14W and 24W 549mm 21W and 39W 849mm 28W and 54W 1149mm 35W, 49W and 80W 1449mm Special sizes for aquariums will not work.
