ELT 3210232 AVS 400-D ignitor universal ignitor for high pressure sodium lamps (SON NAV) 70-400W and metal halide lamps (HQI CDM) 35-400W lenght 89mm included 10mm M8 tread
Properties
Downloads
Your corrections
| Manufacturer's article number | 3210232 | ? Manufacturer's part number. |
| Brand | ELT | ? If the product is unbranded, we do not have a regular supplier for it. Therefore, the product version may slightly vary. |
| Cable capacity output wires mutual | 150pF |
?
Ballasts that include an ignitor to start the HID lamp are limited in the distance between ignitor / ballast and lamp. This capacity in pF may not be higher than the maximum value. A typical value for cable is 100pF/meter. |
| Height | 34mm | ? Maximum height in millimetres. |
| Ignition voltage | 3,5-5,0kV | ? Ignition voltage of the ballast or lamp in kV. |
| Length | 89mm |
?
Product length in millimetres. For fluorescent tubes, this excludes the metal pins on the end unless otherwise stated. |
| Pieces per outer carton | 30 | ? Number of pieces per outer carton. To order full boxes of the item, please add it to your shopping basket in multiples of this amount. |
| Width | 40,5mm | ? Maximum width in millimetres. |
| EAN code | 8435110475608 | ? EAN code is the barcode of an article which is used worldwide as article code. The EAN code extra is the code from the extra packing. |
| EAN code (extra) | ? EAN code is the barcode of an article which is used worldwide as article code. The EAN code extra is the code from the extra packing. |
ELT 3210232 AVS 400-D ignitor
universal ignitor for high pressure sodium lamps (SON NAV) 70-400W
and metal halide lamps (HQI CDM) 35-400W
lenght 89mm included 10mm M8 tread
universal ignitor for high pressure sodium lamps (SON NAV) 70-400W
and metal halide lamps (HQI CDM) 35-400W
lenght 89mm included 10mm M8 tread
Download PDF/29101516 +29101314 .pdf
