TL and LED luminaires surface mounted


Prices are exclusive waste disposal fee.
Prices are exclusive of VAT.

TL and LED luminaires surface mounted
Filters
Filter on:
Either show items that are in stock or items that are not in stock.
? The life span of a party of lamps of which 50% of the lamps will continue to function. Sometimes, incandescent or halogen lamps may become defective more quickly, but in case 50% of the lamps do still reach the lifespan, the lamps are still OK.
? A conventional ballast has a wound coil. It is somewhat cheaper to buy, but more expensive to run because more power is converted into heat. An electronic ballast not only has a lower power consumption, but it also has the advantage of longer lamp life.
? The wider the light beam, the larger the illuminated surface. Brightness decreases as the beam widens, since the light is divided over a larger area.
For creating high contrasts it is therefore recommended to apply smaller light beams. However, contrasts that are too high can be distracting and can cause adjustment problems for the eye, which can be tiring. On the other hand, too little contrast creates a dull and flat impression.
? If the product is unbranded, we do not have a regular supplier for itTherefore, the product version may slightly vary.
?

Luminaire or lamp has a built-in motion detector. The light will switch on when a movement is detected.

? Luminaire or lamp holder is equipped with a switch.
?

Luminaire or lamp has a twilight switch function. This automatically switches on the lights as it gets dark.

? Most common colour in the product.
? Light colour is often represented with a 3 digit number. The first digit indicates the CRI (Colour Rendering Index) or CRI Ra value:
5 = 50-59
6 = 60-69
7 = 70-79
8 = 80-89
9 = 90-99
The last 2 digits are for colour temperature.
The higher the colour temperature, the cooler the impression of light.
Warm white creates a cosy, welcoming atmosphere. Neutral cool-white creates a more businesslike atmosphere.
Low lighting levels in interior must be obtained with warm-white light. If a very high level of light is needed, this must be achieved with neutral or cool white light.
2700K extra warm white
3000K warm white
3500K neutral white
4000K cool white
5000-5500K daylight
6000K cool daylight
? Light sources can be classified on the basis of their colour rendering properties. The unit for colour rendering is called CRI (Colour Rendering Index, or CRI Ra value). The scale of the Ra is from 50 to 100.
Ra = 90-100 excellent colour rendering properties
Ra = 80-90 good colour rendering properties
Ra = 60-80 moderate colour rendering properties
Ra <60 poor colour rendering properties
Fluorescent and PL lamps with an equal power, the luminous flux of Ra 90-100 tubes is typically 20% lower.
?

Colour temperature is expressed in kelvin (K). The higher the colour temperature, the cooler the impression of the light:

2700K: extra warm white
3000K: warm white
3500K: neutral white
4000K: cool white
5000-5500K: daylight
6000K: cool daylight

Extra warm white creates a warm, inviting atmosphere (e.g. hotel, living room, and catering). Warm white can be used for a pleasant atmosphere (e.g. retail and office). Neutral cool white creates a more businesslike atmosphere, this color gives a sterile atmosphere.
Low lighting levels are obtained in interior with warm white light. If a very high level of light is needed, neutral or cool white light is a good choice.

?

The way the power can be connected.

? The way the power can be tapped for looping through.
? Diameter in millimetres, measured at the widest point.
? Some lamps and ballasts are dimmable. There are different types of dimmers and different ways to dim a ballast or transformer. In case of insufficient knowledge, please check with our sales department.
? Not every dimmable ballast or light source can dim to 0% level, here is the dimming range.
? If a luminaire has an emergency function, the autonomy time is indicated here.
? Glass colour.
? Maximum height in millimetres.
?

The IP (Ingress Protection) code indicates the degree of protection against ingress of moisture and solid objects. The code consists of two firures.
The first figure indicates the protection against objects and dust:
IP 0x - not protected
IP 1x - protected against objects with a diameter above 50 mm
IP 2x - protected from objects with a diameter greater than 12 mm (touch safe)
IP 3x - protected from objects with a diameter greater than 2.5 mm
IP 4x - protected against objects with a diameter greater than 1 mm
IP 5x - protected against dust ( dust )
IP 6x - dustproof

The second figure indicats the protection against water:
IP x0 - unprotected (plain)
IP x1 - Protected against dripping water (drip)
IP x2 - Protected against dripping water when tilted to 15 degrees
IP x3 - protected against spraying water (rain tight)
IP x4 - protected against splashing water (splash proof)
IP x5 - protected against water jets (splashproof)
IP x6 - protected from rainstorms
IP x7 - protected against accidental immersion (30 minutes to 1 meter deep) (waterproof)
IP x8 - protected from stay under water (pressure proof)

? Cap, lamp holder or lamp base type.
? Luminaire including or excluding lamp(s).
? Product length in millimetres. For fluorescent tubes, this excludes the metal pins on the end unless otherwise stated.
? Type of lamp that fits in the luminaire. In some cases, several types of lamps can be used in one luminaire.
? Application of the luminaire depending on the environment. For example, an indoor fitting cannot be used outdoors. An outdoor luminaire, on the other hand, could be used indoors, but may be less suitable here, fore example because it provides too much light or is aesthetically unsuitable.
? The amount of light transmitted by the light source per second. The unit of luminous flux is the lumen (lm).
? Material of which the major part of the product is made.
?

Material of which the cover of the product is made.

A Polycarbonate (PC) cover is mechanically much stronger (impact resistant) but less chemically resistant to a number of substances. For general purposes, this is a good choice.

Acrylic (PMMA)  is robust but more resistant to eg hydrochloric acid> 20%, formic acid, 10% nitric acid, ammonia (liquid), often used in piggeries and car washes.

? The life span of a lamp may be limited by the number of switch cycles, which is the number of times a lamp can be switched on and off before it becomes defective.
? The type of reflector which is in the armature located. For TL-D luminaires matt the most applied, dirt on the reflector is not or hardly seen. For T5 fixtures is a high gloss reflector optical much nicer, the luminaire is less seen. In the LTS fittings with SDW-T or SDW-TG lamps for the bakery in the past is often used a gold reflector for a warmer color. For expansion with existing fixtures would be an option. We prefer a silver reflector with possibly a bakery filter because much less distortion of the color displays compared to a gold reflector.
? The number of lights that the luminaire can contain. Most luminaires are supplied without lamps. If lamps are included can be found in filter property Lamp included.
? Number of cores and conductor cross-section of the internal wiring for quick and easy interconnection of fixtures with a cable.
? Type of luminaire application.
? This may be either a fixed voltage or two values​​, in which case the product can be used within these limits.
? The power that the bulb consumes. This does not include the loss of any ballast or transformer.
? Maximum width in millimetres.

40 products     1 2


Philips TCW060 T5 armatuur waterdicht 1x35W IP65 HFP met polycarbonaat kap


PIL Lumis 15-00419 Acro XS T8 2x58W HF (EVSA) dimbaar 1-10V TL opbouwarmatuur IP65 stootvaste acrylaat (PMMA) afdekkap met RVS clips


ALP Tri Proof LED opbouwarmatuur 40W 850 5000K 1255mm IP65 met doorvoerbedrading instelbaar van 30W-40W



Expected shipping date 16-12-2024
ALP Tri Proof LED opbouwarmatuur 60W 850 5000K 1550mm IP65 met doorvoerbedrading instelbaar van 32W-60W



Expected shipping date 16-12-2024
ALP blindschot 1520mm



Expected shipping date 16-12-2024
Ledvance Damp Proof Gen 3 1x1200mm leeg voor LED buis IP65 RVS polycarbonaat kap en RVS dekselklemmen Geschikt voor LED buizen, dummy starter monteren.



4 items in stock
Zalux Ibera LED 4000K kleur 840 opbouwarmatuur IP66 leverbaar met en zonder doovoerbedradinglm


Norton AXP-E LED opbouwarmatuur 33W 840 4000K 4000K IP65 instelbaar op 4 lichtnivo's



Expected shipping date 16-12-2024
Philips Coreline LED 840 4000K LED waterproof WT120C waterdicht opbouwarmatuur IP65 met polycarbonaat kap


Ledvance Damp Proof leeg voor LED buis IP65 RVS polycarbonaat kap en RVS dekselklemmen Geschikt voor LED buizen, leverbaar in meerdere lengtes


Metalmek 6120NW25W-1 LED arm 25,8W 840 1270mm IP65



Expected shipping date 16-12-2024
MacBright artic leeg voor LED buis IP65 RVS polycarbonaat kap en RVS dekselklemmen Geschikt voor LED buizen, leverbaar in meerdere lengtes


Macbright Ocean LED waterdicht armatuur 1275mm of 1575mm 4000K Leverbaar in meerdere vermogens met of zonder noodunit.


T5 minilight armatuur met schakelaar wit 4100K complete set met lamp koelwit, netsnoer 100cm met ministekker, koppelsnoer 20cm, koppelstukje, bevestiging en prismakap


Philips Pacific TCW216 T5 armatuur waterdicht IP66 HFP met polycarbonaat kap in verschillende vermogens en 1 en 2 lamps leverbaar. Ook is er een uitvoering leverbaar met noodstroom.


Philips Ledinaire waterproof WT060C LED56S/840 PLS L1500 46W 4000K kleur 840 LED IP65 waterdicht opbouwarmatuur 1501mm



Expected shipping date 21-12-2024
MacBright BON trogarmatuur 1 of 2 lamps in 36W of 58W leverbaar met conventioneel of elektronisch VSA


MacBright MAB T5 montagebalk EVSA voor TL5 buizen, leverbaar in verschillende vermogens


PIL 3107359 LED opbouwarmatuur TYK+ 30 C/I 85W 3000 K kleur 830 IP66 antraciet



Expected shipping date 16-12-2024
Ledvance Damp Proof 26W 1500mm 4000K kleur 840 IP65 polycarbonaat kap en RVS dekselklemmen voor doorvoerbedrading zie accessoires



4 items in stock
You've viewed 20 of 40 items

40 products     1 2
